Basic Info.
Product Description
Selling point:
1. More energy-saving and environmental friendly
2. More efficient return
3. More reliable and durable
4. More comfortable and safer
5. Convenient maintenance and service
Main specification | Unit | SY215C |
Operating weight | kg | 20975 |
Standard bucket capacity | m³ | 0.93 |
Rated power | kw/rpm | 114/2050 |
Length | mm | 9395 |
Width | mm | 2980 |
Height | mm | 2955 |
Headpiece width | mm | 2710 |
Mouldboard height | mm | 2990 |
Standard mouldboard width | mm | 600 |
Gauge | mm | 2380 |
Minimum ground clearance | mm | 440 |
Tail gyroradius | mm | 2750 |
Tread | mm | 3445 |
Track length | mm | 4250 |
Maximum digging height | mm | 9305 |
Discharge height | mm | 6475 |
Max digging depth | mm | 6630 |
Max vertical arm digging depth | mm | 5980 |
Maximum digging distance | mm | 9885 |
Least radius gyration | mm | 3630 |
Least radius gyration height | mm | 7570 |
Speed of travel(high/low) | km/h | 5.5/3.2 |
Rotating speed | rpm | 11 |
Gradeability | %/° | 70/35 |
Ground clearance | kpa | 45 |
Bucket digging ability | kN | 138 |
Pole digging capacity | kN | 100 |
