Massive Capacity Log Grapple 30-35t Excavator Attachments, for Huge Project, You Need Big Forestry Log Grapple

Get the Massive Capacity Log Grapple 30-35t Excavator Attachment for your large forestry project. Our factory produces high-quality, durable equipment.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
WYJ-300P
Product Type
Forestry & Logging Equipment
Transport Package
Wood Box
Specification
165.5*162.5*118
Trademark
Xuvol
Origin
China
Production Capacity
10000 Pieces/Year

Product Description

Massive Capacity Log Grapple 30-35t Excavator Attachments, for Huge Project, You Need Big Forestry Log Grapple Massive Capacity Log Grapple 30-35t Excavator Attachments, for Huge Project, You Need Big Forestry Log Grapple
1. Model: WYJ-300P
2. Weight: 3000kg
3. Suitable excavator models: 30-35 tons
4. Working pressure: 12~21MPa
5. Rotary drive type: vertical straight tooth, hydraulic brake
6. Clamp drive type: Bunching type, single cylinder and double connecting bar
7. Suitable for large-scale port timber handling construction, eucalyptus handling, bamboo handling, sugarcane handling and other construction occasions, The holding structure will highly improve the operation efficiency.
8. Other name: grabs, excavator grapple, excavator grabs, log grab, excavator attachment, log grab, grapple
Grabs WYJ300P excavator grapple for 30 to 35 ton excavator with 360 hydraulic rotation hot sale excavator grapple attachments
Massive Capacity Log Grapple 30-35t Excavator Attachments, for Huge Project, You Need Big Forestry Log GrappleGrapple Paramenters
Xuvol Grapple Specifications
WYJ-300P







Whole Grapple
Grapple Type
single cylinder/bunching grapple/doubble link
Steel material
Q355B
Optional electric control
add as needed
Height when clamped(mm)
1660
Height when opened(mm)
2417
Width of inner/outer clamp(mm)
779/880
Open Width Max(mm)
3200±30
Minimum holding circle(mm)
<=φ230
Maximum holding circle(mm)
φ1250
Weight (excluding rotation)kg
3000
Suitable Excavator(Ton)
30-35

Rotation Support
Rotation method(grapple)
Internal meshing vertical rotation
Module / raceway diameter
M7/683

Rotation Motor
Motor type grapples
Plunger reduction motor
Pressure(Mpa)
12

Hydraulic cylinder
Rod diameter/bore size
110/160
Pressure(Mpa)
21


Massive Capacity Log Grapple 30-35t Excavator Attachments, for Huge Project, You Need Big Forestry Log GrappleMassive Capacity Log Grapple 30-35t Excavator Attachments, for Huge Project, You Need Big Forestry Log Grapple
FAQ

1. Q:Are you manufacturer?

A:Yes, We are one of the leading mini excavator and excavator attachments manufacturer in China. With 15767m² factory area and 5 production lines.

2. Q:Do you offer OEM service?

A: Yes, We have a professional R&D team which ensure to make your idea turn into reality.

3. Q:How do you make sure the quality?

A:We pass CE and ISO Certificate, grapple products widely used on 90% of global excavator brands, exported to Japan, Vietnam, Indonesia, England and other countries.
Massive Capacity Log Grapple 30-35t Excavator Attachments, for Huge Project, You Need Big Forestry Log Grapple
Guangxi Xuvol Construction Machinery Equipment Co., Ltd.  was established in 2014. On the base of Guangxi Nanning Woyuan Heavy Industry Machinery Equipment Co., Ltd., Xuvol is one of the biggest multi-functional excavator attachments manufacturer in China. Products include OEM grapples, mini excavator, timber harvester head etc. Our R&D Center and production line is located at No. 16, Anping Road, Guangxi-ASEAN Economic and Technological Development Zone, Total construction area is 15767m² including office building and specialized standard factory buildings. Xuvol is a key enterprise in the Guangxi-ASEAN Economic and Technological Development Zone, a national "high-tech enterprise", and also one of the top 100 China construction machinery parts brands. It has accumulated 3 invention patents , 5 appearance patents and 16 utility model patents.

Xuvol has an experienced R&D and production team, using PLE, SLW and three-dimensional design and finite element mechanical to analysis, With CNC boring machine, vertical machining center, gantry machining center, plasma CNC cutting machine, laser cutting machine, three coordinates measuring instruments, welding robots, and environmentally-friendly painting lines, with the above advanced production and processing equipment, to guarantee the quality of products. Xuvol specializes in R&D and production of log grapples, mini excavators of 3.5 tons. At the same time, it develops and produces Woyuan series of excavator fixtures, digging and modifying rock drills, drilling and splitting integrated machines, mobile crushers, hand saws, logging machines and other construction machinery, Complete machines and attachments of forestry machinery and mining machinery.

Xuvol offer OEM and ODM service. Our R&D team ensure to make your idea turn into reality. We firmly believe that quality comes from the trust of customers, and only by innovation. We can do the best in quality and integrity. Massive Capacity Log Grapple 30-35t Excavator Attachments, for Huge Project, You Need Big Forestry Log Grapple
