Te30 Canada Energy & Mining Mini Hydraulic Excavator Cylinder Training Power Engine Pump Technical Sales Excavator

Te30 Canada Energy & Mining Mini Hydraulic Excavator Cylinder- a factory-direct product offering technical sales expertise and powerful engine pump technology.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
TE30
Usage
Mining Excavator, GM Excavator
Bucket
Backhoe
Transmission
Hydraulic Transmission
Drive Type
Internal Combustion Drive
Bucket Capacity
0.1cbm
Size
Small-Scale
Certification
CE, ISO9001: 2000, Euro 5 & EPA Approved
Condition
New
Excavator Width
1350mm
Chassis Ground Clearance
240mm
Volume of Fuel Tank
20L
Transport Length
4180mm
Excavator Height
2200mm
Turning Radius
1300mm
Max.Digging Height
3900mm
Max.Dumping Height
2600mm
Max.Digging Depth
2500mm
Max.Digging Radius
5486mm
Max.Vertical Digging Depth
2300mm
Engine
Changchai / Yanmar
Engine Power
Engine Power
Overall Dimension ( Lxwxh)
4180*1350*2200mm
Weight
2700kg
Transport Package
FCL and LCL
Specification
4180*1350*2200mm
Trademark
TOROS
Origin
Shandong, China
HS Code
8429521200
Production Capacity
5000sets/Month

Product Description

TOROS TE30 Building Material Shops Colombia Construction works Agricultural Garden Digger Machinery China Mini Excavator Hot Sale China Crawler Excavators
Te30 Canada Energy & Mining Mini Hydraulic Excavator Cylinder Training Power Engine Pump Technical Sales Excavator Te30 Canada Energy & Mining Mini Hydraulic Excavator Cylinder Training Power Engine Pump Technical Sales Excavator TE 30 Rugged and durable, low investment and high return.

TE30 Crawler Excavators using Changchai three-cylinder water-cooled engine, can meet tier II&III standard, supply first-class fuel supply capacity; Using high-quality full hydraulic system:Taifeng plunger pump, northern multi-way valve, Eaton travel and swing motor, extend the service life of the machine and strengthen the working ability; Standard rubber crawler equipped mechanical walking, ensure the maximum walking speed while protecting the ground and reducing noise;The canopy/cab can be adjusted, and various assistive devices can be selected to make your work handy. Really achieve "fast", "strong", "economical" and "long-term".
TE30 Mini Crawler excavator
METRIC    IMPERIAL
Bucket Capacity 0.1m³ Bucket Capacity 3.53ft³
Excavator Width 1350mm Excavator Width 53.15in
Track Length 2000mm Track Length 78.74in
Chassis Ground Clearance 240mm Chassis Ground Clearance 9.45in
Track Width 230mm Track Width 9.06in
Volume of fuel tank 20L Volume of fuel tank 4.4UK gal
Gradeability 30° Gradeability 86ºF
Transport Length 4180mm Transport Length 164.57in
Excavator Height 2200mm Excavator Height 86.61in
Overall Dimension ( LxWxH) 4180*1350*2200mm Overall Dimension ( LxWxH) 164.57*53.15*86.61in
Multi-way Valve EATON Traveling Motor Multi-way Valve EATON Traveling Motor
Engine CHANGCHAI / YANMAR Engine CHANGCHAI / YANMAR
Engine Power 24.5kw/2200rpm  19.6KW/2300rpm Engine Power 32.86hp/2200rpm 26.28hp/2300rpm
Turning Radius 1300mm Turning Radius 51.18in
Max.Digging Height 3900mm Max.Digging Height 153.54in
Max.Dumping Height 2600mm Max.Dumping Height 102.36in
Max.Digging Depth 2500mm Max.Digging Depth 98.43in
Max.Digging Radius 5486mm Max.Digging Radius 215.98in
Max.Vertical Digging Depth 2300mm Max.Vertical Digging Depth 90.55in
MAX.Digging Force 22KN MAX.Digging Force 22KN
Weight 2700kg Weight 5952lb 7.70oz
EATON Swing Motor Taifeng Plunger Hydraulic Pump EATON Swing Motor Taifeng Plunger Hydraulic Pump
Te30 Canada Energy & Mining Mini Hydraulic Excavator Cylinder Training Power Engine Pump Technical Sales Excavator Te30 Canada Energy & Mining Mini Hydraulic Excavator Cylinder Training Power Engine Pump Technical Sales Excavator Te30 Canada Energy & Mining Mini Hydraulic Excavator Cylinder Training Power Engine Pump Technical Sales Excavator Te30 Canada Energy & Mining Mini Hydraulic Excavator Cylinder Training Power Engine Pump Technical Sales Excavator Te30 Canada Energy & Mining Mini Hydraulic Excavator Cylinder Training Power Engine Pump Technical Sales Excavator Te30 Canada Energy & Mining Mini Hydraulic Excavator Cylinder Training Power Engine Pump Technical Sales Excavator
